High-Power Continuous Sealer
CBS-1100H Multi-Function High-Power Continuous Sealing Machine
Built for the line, not the bench. The CBS-1100H uses a high-power heater and continuous drive to seal, make bags and print plastic film without stopping, with an unlimited seal length and automatic overheat protection. When a sealer has to keep pace with filling equipment for a full shift, this is the class of machine that does it.
ContinuousDuty cycle
UnlimitedSeal length
3-in-1Seal, bag, print
5AProtected fuse
Overview
One Platform, Three Jobs, Continuous Motion
Sealing, bag making and printing are usually three stations. The CBS-1100H folds them onto one continuous platform, so a film web can be made into bags, closed and coded without being transferred between machines.
Sealing
A high-power heater brings the seal zone up to temperature quickly and holds it under continuous load.
Bag Making
The same belt path can form bags from film tube, so short runs of a bespoke size do not need new tooling.
Printing
Date, batch and lot data can be printed during the same pass, so no pack leaves uncoded.
Continuous Cycle
How the Platform Runs Without Stopping
Because the heater and the drive are sized for continuous duty, the four stages repeat back to back instead of in separate cycles.
01
Load
The film or filled bag is placed on the delivery table and guided into the moving sealing belts.
02
Seal
The high-power heating block fuses the film under steady temperature, with the seal length unlimited.
03
Set
The sealed section leaves the heating zone and cools, so the pattern holds its shape.
04
Date, batch or lot data is printed during the same continuous pass, so the pack leaves finished.
Technical Data
CBS-1100H Datasheet
The datasheet describes this model by function, duty and safety limits rather than by numeric ratings, so the table below lists the parameters as supplied.
| Parameter | CBS-1100H |
|---|---|
| Type | Multi-function horizontal continuous sealing machine |
| Duty | Continuous operation |
| Functions | Sealing, bag making and printing |
| Seal Length | Unlimited |
| Power Line | Single-phase three-wire |
| Fuse | 5 A, must not be uprated |
| Overheat Protection | Continuous buzzer and yellow fault indicator |
| Suitable Materials | Plastic film bags for food, pharmaceutical, daily goods, local produce, chemical, electrical component and garment packing |
| Not Suitable For | Metal containers, metal caps and metal tabletops |
| Installation | Dry floor, aviation plug inserted and screw locked before power-on |
Voltage, plug type and the printing unit are confirmed against your film and line layout before production.
Duty Matrix
Matching Heat Input to Film and Shift Length
A high-power machine is not always needed. Use this matrix to judge whether the CBS-1100H is the right class for your film and your daily run time.
| Film / Pack | Seal Demand | Shift Pattern | Recommended Class |
|---|---|---|---|
| Thin PE pouches | Low, short dwell | Intermittent | Bench continuous sealer |
| Standard retail bags | Medium | One to two shifts | Bench or floor continuous sealer |
| Wide seal on coated film | High | Continuous | CBS-1100H |
| Composite or heavy bags | High | Continuous line | CBS-1100H |
| Bag making from film tube | High, repeated | Continuous line | CBS-1100H |
Class recommendations are practical guidance rather than fixed rules. Share the film specification and line speed and we will confirm the right build for your product.
Safe Operation
Rules That Keep a High-Power Sealer Reliable
High-power sealing means high voltage and a hot head. The operating rules below are the difference between years of service and an early failure.
- No metal on the machineDo not use metal containers or metal caps, and never stand the machine on a metal tabletop or press start there, because the field couples into metal and damages the unit.
- Lock the plug firstInsert the induction aviation plug and tighten its screw before switching on the supply.
- Dry, grounded powerUse a single-phase three-wire line and keep the floor dry to maintain insulation.
- Watch the overheat signalIf the buzzer sounds continuously and the yellow lamp lights, switch off the main supply and let the machine cool before restarting.
- Check the head surfaceFeel the induction head regularly; if it is too hot to touch, stop heating and let it cool.
- Correct fuse onlyThe fuse is rated 5 A and must not be replaced with a higher value. Do not attempt internal repairs; the base carries high voltage.
Advantages
Why Choose a High-Power Build
Heat Reserve
Extra heater capacity holds the set point when film draws heat faster than a light machine can replace it.
Steady Line Speed
Continuous output lets the sealer follow upstream filling or forming equipment without buffer stock.
Protected Duty
Automatic overheat protection with a buzzer and lamp guards the heater and electronics during long runs.
Wide Material Coverage
Seals the plastics used in food, pharma, daily goods, local produce, chemical, electrical and garment packing.
Key Numbers
The CBS-1100H at a Glance
3-in-1Seal, bag and print
UnlimitedSeal length
5AFuse rating
1‑phaseThree-wire supply
Applications
Sectors That Run the CBS-1100H
A continuous high-power sealer suits any plant where film packing is part of a flow, not a batch.
Food & Daily Goods
Film packs of food, local produce and household items sealed at line speed with a printed code.
Pharmaceutical
Small components and dry products in film packs that need a consistent seal at steady output.
Chemical, Electrical & Garment
Hardware, electrical components, textiles and craft goods packed in film for storage and transport.
Ordering & Support
What Comes With Every CBS-1100H
Shipping
Heavy double-layer packing resists impact, pressure and moisture, and ships by express, air or sea.
Payment
T/T bank transfer and other agreed methods, with terms confirmed on the proforma invoice.
Warranty
A 2-year warranty covers parts and labour, with fast supply of fuses, heaters and cloth.
Commissioning
Video guidance sets the temperature, belt speed and print position for your film before first production.
- Lead timeAbout 5 working days for standard builds, plus roughly 4–6 working days in transit by express.
- Volume termsAgreed per order against quantity and destination — send your target volume and port.
- OEM & ODMNameplate, colour and imprint content can carry your brand.
- Sample testSend your film and we will confirm the setting that gives a clean, strong seal.
FAQ
CBS-1100H Questions
The heater and drive are sized for continuous duty rather than short cycles. That lets the machine seal, make bags and print without cooling pauses, which matters when film needs a higher heat input, when the seal is wide, or when the line runs for hours at a steady rate.
Yes. The platform is designed for continuous operation with an unlimited seal length, so the film can pass without stopping. It is the format normally chosen for a production line where the sealer has to keep pace with upstream filling or forming equipment.
If the internal temperature rises too far, a buzzer sounds continuously and a yellow fault indicator lights. At that point the operator should switch off the main supply and let the machine cool before restarting. This protects the heater and the electronics during long or heavy runs.
It uses a single-phase three-wire power line and the work area floor must be dry to maintain insulation. The induction aviation plug must be inserted and its screw locked before the supply is switched on, and the 5 A fuse must never be replaced with a higher rating.
Metal containers and metal caps should not be used, and the machine must not stand on a metal tabletop, because the induction field would couple into the metal and damage the equipment. Keep the induction head free of metal objects and check its surface for overheating during use.
It is assembled and tested before dispatch and shipped in heavy double-layer packing that resists impact, pressure and moisture in transit. Standard production is about 5 working days with express transit of roughly 4 to 6 working days. Fuses, heaters and high-temperature cloth are supplied as consumables.
