Field Service Laser Cleaning
Trolley-Case Pulsed Laser Cleaning Machine
MOPA-level precision in a case that travels like luggage. With a retractable handle and a weight range of 25 to 45 kg, one technician can carry it to the job, extend the handle and roll it straight across the floor. The pulsed beam removes oil, coating, oxide and rust without touching the substrate, so laser-cut edges and precision surfaces keep their tolerances. Air cooling means no water circuit, no coolant to freeze, and no leak risk in the back of a service van.
25–45kgNet weight by configuration
1.5–2.0mJPulse energy
0–150mmAdjustable scan width
8Cleaning paths
Form Factor
A Case That Travels Like Luggage
Portability is not only about weight. It is about how the machine behaves between jobs — in a van, up a flight of stairs, through a service door and across a shop floor. This system was designed for that journey as much as for the cleaning itself.
- Retractable handleCarry it by hand, then extend the handle and roll it once you are on a hard surface.
- Fits a car bootA single operator transports it in a standard car, which is what makes on-site service practical.
- Air cooling, no waterNo coolant to drain before transport and no leak risk; it also runs in sub-zero and dry conditions.
- Maintenance free opticsAn integrated fiber design with a sealed cleaning head, a durable lens and a protected window holder.
- Instant stopAn emergency stop button cuts power immediately, and the head carries a gas port to keep the window clear.
Process Comparison
Portable Pulse Against Other Cleaning Methods
The comparison is about where the process can go and what it does to the part, not only how fast it cleans.
| Metric | Portable Pulsed Laser | Standard Continuous Laser | Manual or Chemical |
|---|---|---|---|
| Portability | Extreme, carry-on case | Heavy, needs a trolley or forklift | Requires bulk chemicals or media |
| Substrate Safety | Non-destructive, no heat damage | Risk of melting or surface deformation | Risk of scratching or acid attack |
| Precision Control | Micron-level depth control | Broad area cleaning only | Depth difficult to control |
| Environmental Impact | 100 percent clean, no dust plume | Low dust | Toxic waste water and chemical residue |
| Consumables | None beyond electricity | None beyond electricity | Solvent and abrasive supply |
| Works In Place | Yes, at the component | Limited by the cable and weight | Requires containment and clean-up |
Product Details
Four Subsystems That Make the Case Work
Every module is chosen for reliability in transit and repeatability on the part.
Laser Generator
World-class technology in a modular, redundant design. Compact, with high beam quality, low energy draw and stable output across different applications. No fittings needed and no maintenance.
Cleaning Head
A stable, well-sealed head with a durable lens and efficient cooling. The protective lens holder and gas port on the body extend continuous working time and protect the optics.
Control System
Professional cleaning software with eight cleaning paths, per-layer parameters, and a splice mode that joins tracks automatically for large continuous work.
Emergency Stop
An oversized stop button cuts power instantly, giving operators an immediate and unambiguous response in any situation.
Key Numbers
The Essential Figures
Four numbers that describe what the case delivers on a service visit.
25–45kgNet weight range
1.5–2.0mJPulse energy
150mmMaximum scan width
8Cleaning paths
Software and Control
How the Controller Handles Multi-Layer Cleaning
The control system turns an operator's intent into repeatable coverage, layer by layer.
01
Choose a Path
Select from eight cleaning paths to suit the geometry, from a simple sweep to a filled pattern.
02
Set Per-Layer Parameters
Assign a different setting to each layer of a coating so the top film is stripped without attacking what lies beneath.
03
Splice the Tracks
The splice mode joins consecutive passes automatically, so coverage stays continuous across a large area without manual overlap.
04
Optimize and Repeat
Patterns can be adjusted and saved, so a proven graphic design or cleaning route is reused on the next visit.
Applications
Built for Field Service and Precision Repair
The case format is chosen by technicians who need MOPA precision on a customer site.
A
Aerospace Field Service
Coating and oxide removal on installed components, where precision and a documented, non-destructive process are both required.
B
Precision Component Repair
Tooling, molds and machined parts cleaned without altering tolerances or the original surface finish.
C
Workshop Quality Cell
Fast edge and dross cleaning after laser cutting, ready for assembly or high-strength welding.
“A customer in Colombia needed to clean stainless steel cutlery and kitchenware across a range of finishes. We specified a pulsed laser cleaner for the job, and the unit has handled the variety of shapes and surface conditions comfortably.”
Application Engineer · Surface finishing project, Colombia
Technical Data
Core Parameters of the Case Machine
Key figures for the standard configuration. Options are confirmed per order.
| Parameter | Specification |
|---|---|
| Transport Format | Case with retractable handle, single-person handling |
| Laser Technology | MOPA pulsed fiber laser, JPT or Raycus |
| Pulse Energy | 1.5–2.0 mJ |
| Scan Width | 0–150 mm, adjustable |
| Cooling System | High-efficiency air cooling, maintenance free |
| Net Weight | Approx. 25–45 kg depending on configuration |
| Control Software | Eight cleaning paths, per-layer parameters, splice mode |
| Safety | Emergency stop, protected optics, sealed cleaning head |
| Preset Materials | Stainless steel, aluminium and carbon steel |
The source material for this model describes a small water use in one section, while the technical parameter table confirms air cooling with no water circuit. We follow the parameter table; the machine is supplied air-cooled. Ask us for a specification matched to your parts.
Ordering & Support
Field Support for a Field Machine
Help is delivered remotely, so a technician on site is never left waiting for a visit.
Shipping
Air express and freight options with export packing, trackable from the factory door.
Payment
T/T bank transfer, PayPal and Western Union. Terms and Incoterms are confirmed on the proforma invoice.
Warranty
Parts and labour covered, with free replacement components and lifetime technical support.
Operator Training
Preset modes and a short training session bring a new technician to industrial cleanliness standards quickly.
- Free sample testSend a sample and we return it cleaned with the path and parameters we used.
- Volume termsAgreed per order against quantity and destination — send your target volume and port.
- OEM & ODMCase branding, interface language and documentation can be adapted to your market.
- Configuration optionsScan width, preset material set and accessories are specified per order.
FAQ
Trolley-Case Laser Cleaning Questions
Portability is the priority. The 100W to 200W pulsed laser technology in this machine is optimized for efficient air cooling, which makes the unit lighter, lets it run at very low ambient temperatures, and removes the risk of a coolant leak in transit. Only very high power processing in the 10 kW class requires active water cooling.
Yes, and this is the main advantage of a pulsed system. Because the energy is released in nanosecond bursts, the beam vaporizes contamination before heat can penetrate the substrate. Laser-cut precision and the original surface profile of the part are preserved.
In a shop running a steel sheet laser cutter, edges often retain oxide or dross. The portable unit lets a worker move along the production floor and clean those edges quickly, ready for precision assembly or high-strength welding, without sending the part to a separate cleaning station.
It is as straightforward as handling a suitcase. Preset modes for stainless steel, aluminium and carbon steel are provided, and even a new operator can reach industrial cleanliness standards after about five minutes of training.
The case contains the laser generator, the cleaning head with its protective lens holder and gas port, the control system, and the emergency stop. The control software supports eight cleaning paths with per-layer parameters and a splice mode for continuous coverage across large areas.
The machine carries a manufacturer warranty covering parts and labour, with free replacement components during the warranty period and lifetime technical support by email, messaging and remote assistance.
